Anritsu S820E Microwave Site Master 1 MHz to 20 GHz

SKU: ANR,S820E

Microwave antenna and cable analyser, frequency range 1 MHz to 20 Ghz with 110 dB dynamic range. Coaxial and waveguide system measurements include 1-port Return Loss, VSWR, Cable Loss, Distance-To-Fault and VSWR, Smith Chart, transmission and phase measurements. Unit comes standard with USB interface, smith chart and software management tools. Supplied with K(m) type port (compatible with 3.5mm and SMA), the S820E Sitemaster also includes "Classic Mode" which allows former users of the S8X0D series to become immediately productive with a minimal additional effort. A range of waveguide calibration components are separately available to rent.

Need this equipment?

Add to your quote cart and submit a request. We'll get back to you within 24 hours with pricing and availability.

Call us: +61 2 9564 8623
